Description
ÖLFLEX® FD 855 P is designed for extreme mechanical stresses due to a tighter bend radius in continuous flex applications. Materials are halogen-free and environmentally friendly with an expand temperature range. The polyurethane jacket is mechanically and chemically resistant to many environments. ÖLFLEX® FD 855 CP is a shielded version available with an overall tinned copper braid. This is recommended when electrical interference needs to be suppressed. LAPP part number 0027373.
| MANUFACTURER LAPP |
MANUFACTURER PART NUMBER 0027373 |
SERIES ÖLFLEX® FD 855 P |
| AWG/GAUGE 14 |
NUMBER OF CONDUCTORS 7 |
CONDUCTOR MATERIAL Bare copper |
| CONDUCTOR STRANDING Stranded |
JACKET COLOR Gray |
JACKET MATERIAL Polyurethane (PUR) |
| NOMINAL OD (IN) 0.528 |
NOMINAL OD (MM) 13.4 |
INSULATION TPE |
| VOLTAGE 1000V |
DYNAMIC TEMPERATURE RATING -40°F to +176°F -40°C to +80°C |
STATIC TEMPERATURE RATING -58°F to +176°F -50°C to +80°C |
| ATTRIBUTES Multi-Conductor |
STANDARDS/APPROVALS CE Approved UL AWM 21576 |
WEIGHT LBS/MFT 179 |
