Description
GAM helical pinion, Module 2, 18 tooth, keyed shaft mount. For use with SureGear PGCN34 series gearboxes.
Brand: GAM
Item: Pinion
Tooth Profile: Helical
Pressure Angle: 20 degrees
Module: 2
Pitch Diameter: 38.197mm
Number of Teeth: 18
Travel per Rotation: 120mm
Maximum Force Feed: 2.8 kN
Mounting: Keyed shaft
Mounting Distance: 41.1mm
Material: 4140 carbon steel
Hardness: 55 – 60 HRC
Finish: Ra 0.8
Precision Grade: ISO Q06
For Use With: SureGear PGCN34 series gearboxes
Item: Pinion
Tooth Profile: Helical
Pressure Angle: 20 degrees
Module: 2
Pitch Diameter: 38.197mm
Number of Teeth: 18
Travel per Rotation: 120mm
Maximum Force Feed: 2.8 kN
Mounting: Keyed shaft
Mounting Distance: 41.1mm
Material: 4140 carbon steel
Hardness: 55 – 60 HRC
Finish: Ra 0.8
Precision Grade: ISO Q06
For Use With: SureGear PGCN34 series gearboxes
