Description
Accupro 1″ Diam 7 Flute Solid Carbide 0.03″ Corner Radius End Mill nACRo Finish, 4″ OAL, 2″ LOC, 1″ Shank Diam, 37° Helix, RH Cut, RH Flute, Centercutting
Manufacturer Part #: 12177394
S/N: 58750613
UNSPSC: 27112803
(Minimum Order Quantity=1, Package Quantity=1)
Specifications:
| Mill Diameter (Inch) | 1in |
| Mill Diameter (Decimal Inch) | 1.0000in |
| Number Of Flutes | 7 |
| Length of Cut (Inch) | 2in |
| Single Or Double End | Single |
| End Mill Material | Solid Carbide |
| Coating/Finish | nACRo |
| Overall Length (Inch) | 4in |
| Centercutting | Yes |
| Flute Direction | Right Hand |
| Corner Radius (Decimal Inch) | 0.0300 |
| Variable Index | Yes |
| Cutting Direction | Right Hand |
| Overall Length (Decimal Inch) | 4.0000in |
| End Type | Corner Radius |
| Length Of Cut (Decimal Inch – 4 Decimals) | 0.5000in |
| Flute Type | Spiral |
| Extended Reach | No |
| Shank Diameter (Decimal Inch) | 1.0000 |
| Shank Diameter (Inch) | 1in |
| Corner Radius Tolerance | 0.00150 in |
| Mill Diameter Tolerance | +0.000000/-0.002500 in |
| Shank Diameter Tolerance | -0.0001/-0.0004 in |
| UNSPSC Code | 27112803 |
| Material Grade | Micrograin |
