Autel MaxiCheck MX900 All-System and Service Diagnostic Scanner

Description

Autel MaxiCheck MX900 All-System and Service Diagnostic Scanner

The MaxiCheck MX900 is an 8″ touchscreen, all-systems scanner, and service tablet. This powerful, corded tablet can read and erase codes, view Freeze Frame and, view and graph Live Data, and perform bi-directional Active Tests and Special Functions. The MX900 is also a full-featured service tablet with more than 40 Service and maintenance tasks, including Brake Bleed, Oil and Service lights resets, Battery registration, DPF regen, and Electronic Parking Brake and Steering Angle resets. The MX900 runs on Android 11 and is powered by 1.8 GHZ processor. The MaxiCheck MX900 also includes one year of software updates and a limited warranty.

Specifications:

Operating System:	Android 11
Memory:	4GB RAM / 64GB On-Board ROM Memory
Processor:	1.8 GHz Quad Core Processor
Display:	8-inch LED capacitive touchscreen with 1280×800 resolution
Camera:	Rear: 8 Megapixel
Battery:	7700mAh 3.7 V lithium-polymer battery
Connectivity:	Wi-Fi (802.11 a/b/g/n) Mini USB 2.0 Micro SD Card
Operating Temperature:	0 to 50 °C (32 to 122 °F)
Storage Temperature:	-10 to 60 °C (14 to 140 °F)

Extraordinary Diagnostics:

• Extensive vehicle coverage for U.S., Asian, and European vehicle makes
• Read/Erase Codes, View/Graph Live Data
• Preforms Active Tests and Special Functions
• Smart AutoVIN technology for identifying vehicles easily
• Supports DoIP and CAN FD protocols
• Preforms Pre & Post Scan
• Supports all OBDII protocols and 10 test modes

Advanced Service Functions:

Supports 40+ maintenance service functions including:

• Forced Diesel Particulate Filter (DPF) regeneration
• Steering Angle Sensor (SAS) reset
• Oil Light Service and battery registration
• Resets service mileage and service intervals
• EPB Reset and Preform Brake Bleed

Download:

• MaxiCheck MX900 Flyer
