Description
Cleveland Twist Drill 17/64″ 118° High Speed Steel Jobber Drill Bright Finish, Right Hand Cut, Spiral Flute, Straight Shank, 4-1/8″ OAL, Standard Point
Manufacturer Part #: C03081
S/N: 63700173
UNSPSC: 23241634
UPC: 697334030812
(Minimum Order Quantity=1, Package Quantity=1)
Specifications:
| Drill Bit Size (Inch) | 17/64 |
| Drill Bit Size (Decimal Inch) | 0.2656 |
| Drill Bit Material | High Speed Steel |
| Drill Point Angle (Degrees) | 118 |
| Flute Type | Spiral |
| Cutting Direction | Right Hand |
| Point Type | Standard |
| Primary Workpiece Material | Aluminum |
| Coolant Through | No |
| Number of Flutes | 2 |
| Drill Bit Finish/Coating | Bright/Uncoated |
| Flute Length (Inch) | 2-7/8 |
| Overall Length (Inch) | 4-1/8 |
| Spiral Type | Fast |
| Series | 2012 |
| Shank Diameter (Inch) | 17/64 |
| Shank Length (mm) | 31.75 |
| Shank Length (Decimal Inch) | 1.2500 |
| Drill Bit Diameter Tolerance | -0.0010 to 0.0000 in |
| Web Thinning | Web-Thinned |
| Web Configuration | Tapered |
| Shank Type | Straight-Cylindrical |
| Standards | ASME B94.11M |
| Drill Bit Grade | General Purpose |
| Drill Bit Size Range (Decimal Inch) | 0.2500 – 0.3000 |
| Specification Designation | ANSI |
| UNSPSC Code | 23241634 |
