Description
KYOCERA DCMT32.51HQ TN60 Cermet Turning Insert TiCN/NbC Finish, Neutral, 0.433″ Long, 3/8″ Inscribed Circle, 1/64″ Corner Radius, 55° Diamond
Manufacturer Part #: 8835940
S/N: 85927705
UNSPSC: 23242105
(Minimum Order Quantity=1, Package Quantity=1)
Specifications:
| Relief Angle | 7 |
| Insert Style | DCMT |
| Corner Radius (Inch) | 1/64 |
| Corner Radius (Decimal Inch) | 0.0156 |
| Included Angle | 55degree |
| Manufacturer Grade | TN60 |
| Coating/Finish | TiCN, NbC |
| Wiper Edge | No |
| Insert Hand | Neutral |
| Insert Thickness (Inch) | 5/32 |
| Insert Thickness (Decimal Inch) | 0.1563 |
| Series | ISOI |
| Inscribed Circle (Inch) | 3/8 |
| Inscribed Circle (Decimal Inch) | 0.3750 |
| Insert Material | Cermet |
| Insert Shape | Diamond 55 |
| Number Of Cutting Edges | 2 |
| Insert Shape Code | D |
| Hole Diameter (Decimal Inch) | 0.1732 |
| Maximum Depth of Cut (Decimal Inch) | 0.3047 |
| Insert Holding Method | Screw |
| Width (Inch) | 3/8in |
| Clearance Code | C |
| Tolerance Code | M |
| Coating Process | Uncoated |
| Length Range (Decimal Inch) | 0.7000 – 10.0000 |
| Rake | Positive |
| Insert Length (Decimal Inch) | 0.9140 |
| Primary Workpiece Material | Steel |
| Primary Workpiece Material Code | P |
| Iso Code | DCMT11T304HQ |
| Standards | ANSI, ISO |
| Manufacturers Catalog Number | TSJ00738 |
| Material Grade | P01, P10, P20 |
| Coating Classification | Uncoated |
| Chip Breaker | HQ |
| Rake Angle | 15 |
| Cutting Edge Style | Honed |
| Industry Standard Number | DCMT3251HQTN60 |
| Width (Decimal Inch – 4 Decimals) | 0.3750in |
| Multi-Use Tool | Yes |
| Full Radius | No |
| Multi-Use Application | Back Boring, Copying, External Turning |
| UNSPSC Code | 23242105 |
| Insert Size Code | 3251 |
