Description
Precision Twist Drill #19 135° High Speed Steel Jobber Drill Bright Finish, Right Hand Cut, Parabolic Flute, Straight Shank, 3-1/4″ OAL, Split Point
Manufacturer Part #: 019419
S/N: 78526308
UNSPSC: 23241634
UPC: 086071194190
(Minimum Order Quantity=1, Package Quantity=1)
Specifications:
| Drill Bit Size (Wire) | #19 |
| Drill Bit Size (Decimal Inch) | 0.1660 |
| Drill Bit Material | High Speed Steel |
| Drill Point Angle (Degrees) | 135 |
| Coating/Finish | Bright/Uncoated |
| Flute Type | Spiral |
| Cutting Direction | Right Hand |
| Point Type | Standard |
| Primary Workpiece Material | Steel, Stainless Steel, Cast Iron, Non-Ferrous Metal, Superalloys & Titanium, Hard Material |
| Coolant Through | No |
| Number of Flutes | 2 |
| Flute Length (Inch) | 2-1/8 |
| Primary Workpiece Material Code | P, M, K, N, S |
| Shank Diameter (Decimal Inch) | 0.1660 |
| Overall Length (Inch) | 3-1/4in |
| Overall Length (Decimal Inch) | 3.2500in |
| Spiral Type | Regular |
| Flute Length (Decimal Inch) | 2.1250 |
| Series | QC21P |
| Tool Application | Drilling |
| Flute By Diameter Ratio | 13xD |
| Maximum Drilling Depth (Decimal Inch) | 2.1250 |
| Maximum Drilling Depth (Inch) | 2-1/8 |
| Shank Length (Decimal Inch) | 1.1250in |
| Shank Length (Inch) | 1-1/8in |
| Number of Flats | 0 |
| Web Thinning | Web-Thinned |
| Web Configuration | Tapered |
| Shank Type | Straight-Cylindrical |
| Tool Performance | General Purpose |
| Standards | ANSI |
| Double Margin | No |
| Drill Bit Grade | Heavy Duty |
| Drill Bit Size Range (Decimal Inch) | 0.1500 – 0.2000 |
| Specification Designation | ANSI |
| UNSPSC Code | 23241634 |
